| Sensor | A Third Color CMOS Image Sensor |
| Format | PAL/NTSC |
| Pixel | 628 * 582/510 * 492 |
| The TV Line | 420, 380 |
| The Angle | 92/120 |
| Working Voltage | DC12V |
| TV System | NTSC |
| The Level of Clarity | 420 TV Lines |
| Pixel | 656 x 492 Pixels |
| Photosensitive Area | 4.08 mm * 3.12 mm |
| The Shutter Speed | 1/60-1/20000 |
| Video Output | 1.0 the VP - P, 75 OHM |
| Gamma Factor | 0.45 |
| White Balance | Auto |
| Scanning System | 2:1 Interlace |
| The Lens Angle | 170o or 135o |
| Waterproof Level | IP67/68 |
| Minimum Illumination | 0.1 Lux/F = 1.2 (0 Lux with IR on) |
| Power Supply | DC 12V |
| Working Temperature | - 20? to 75?, 95% RH MAX |
| Storage Temperature | - 40? to 85?, 95% RH MAX |
| Dimensions | (3.54 x 0.39 x 0.39)" / (9 x 1 x 1)cm (L x W x H) |
| Weight | 3.35oz / 95g |
| Material | Plastic |
| Coloe | Black |
